Description
Camozzi 354‑015‑02 (Series 3) is a monostable, 5/2-way solenoid valve with spring return. It features internal pilot actuation and is built for reliable control in pneumatic systems.
-
Valve Function: 5 ports, 2 positions (5/2), monostable (returns to default position via spring)
-
Actuation Type: Single solenoid (solenoid not included); pilot pressure is internal
-
Flow Rate: 1300 Nl/min
-
Working Pressure Range: 1.4 – 10 bar
-
Port Thread: G 1/4" (P, A, B, R, S ports)
-
Construction Materials:
-
Body: Aluminum
-
Valve spool (slider): Stainless steel
-
Seals: Nitrile rubber (NBR)
-
-
Mounting: Can be mounted individually or on manifold plates; installable in any orientation
-
Manual Override: Screw-type manual override available
-
Operating Temperature: 0 °C to +60 °C (down to –20 °C with dry air)
-
Air Quality: Clean, filtered air (preferably ISO 8573‑1: [7:4:4])
-
Solenoid Compatibility: Accepts solenoids from Series U, G (22×22 mm)
-
Service Life: At least 40 million cycles
-
Body Weight: Approx. 281 grams
