CAMOZZI SWCN-P10-P4-2 electronic vacuum
Eurolux
> 24 Hrs
100%
Description
CAMOZZI SWCN-P10-P4-2 is an electronic pressure/vacuum switch designed for precise pressure monitoring and control. It features a digital display and two PNP outputs.
-
Pressure range: 0 to 10 bar
-
Max pressure: 15 bar
-
Outputs: 2 PNP outputs (NO or NC configurable)
-
Power supply: 12–24 V DC
-
Current consumption: ≤ 55 mA
-
Display: 3-digit LED, membrane keypad
-
Indicators: Green (Output 1), Red (Output 2)
-
Repeatability: ≤ ±0.2% of full scale
-
Temperature drift: ≤ ±2% FS ±1 digit
-
Protection class: IP65
-
Material: Polycarbonate body
-
Connection type: G 1/8” pressure port, 2 m cable (5 wires)
-
Mounting: M4 holes, 20 mm apart
-
Operating temperature: 0 °C to +50 °C
-
Storage temperature: –20 °C to +60 °C
-
Weight: approx. 105 g
-
Media compatibility: Non-corrosive, non-flammable gases (e.g., air)
