Lightware DCX-3x1-TPX-TX10 USB-C and HDMI AV over IP Switcher

Description

Lightware DCX-3x1-TPX-TX10 is a professional USB Type-C and HDMI 2.0 transmitter switcher designed for SDVoE-based 10G AV over IP installations. It combines two HDMI 2.0 inputs with a USB-C input supporting DisplayPort Alt Mode, enabling professional distribution of video, audio, Ethernet and control signals through a 10GBase-T network connection.

The device supports 4K@60Hz RGB 4:4:4 video with up to 18 Gbps bandwidth and 5K ultrawide 5120×2160 signals via HDMI 2.0 at 30Hz 4:4:4 or 60Hz 4:2:0. USB-C connectivity provides video, audio and charging power up to 100 W, making it particularly suitable for modern meeting rooms, collaboration environments, control rooms, engineering, simulation and professional AV applications.

Key Specifications

• USB-C input: 24-pin USB Type-C, DP 1.2a
• HDMI inputs: 2 × HDMI 2.0 Type A with screw-lock
• HDMI/DVI standards: DVI 1.0, HDMI 1.4, HDMI 2.0
• Maximum bandwidth: 18 Gbps
• Maximum video: 4096×2160@60Hz RGB 4:4:4
• 5K support: 5120×2160@30Hz 4:4:4 or 60Hz 4:2:0
• USB-C charging: up to 100 W
• HDCP: 1.4 / 2.2
• Color space: RGB, YCbCr
• Video delay: 0 frames
• 3D support: Yes
• HDMI output: 1 × HDMI Type A
• TPX output: RJ45, 10GBase-T
• Transmitted signals: Video, audio and Ethernet
• TPX video support: up to 4096×2160@60Hz 4:4:4
• Audio: 8-channel PCM, Dolby TrueHD, DTS-HD Master Audio 7.1
• Analog audio output: 5-pin Phoenix, 2-channel PCM, 48 kHz
• Control port: RJ45, 10/100/1000Base-T Full Duplex
• PoE: Not supported
• External power supply: 160 W
• Power input: 100–240 V AC, 50/60 Hz
• Operating temperature: 0…+50°C
• Operating humidity: 10–90%, non-condensing
• Cooling: Fan
• Enclosure: 1 mm steel
• Dimensions: 271 × 140.3 × 26 mm
• Weight: 1060 g
• Warranty: 3 years
• Compliance: CE, UKCA, RoHS

Advantages

• Designed for professional SDVoE-based 10G AV over IP systems.
• Supports high-quality 4K@60Hz RGB 4:4:4 transmission.
• Supports 5K 21:9 ultrawide displays.
• Up to 100 W USB-C charging for connected laptops.
• Transmits video, audio and Ethernet over a 10GBase-T connection.
• Compatible with Taurus UCX, DCX and HDMI-TPX ecosystem devices.
• Suitable for conference rooms, control rooms, broadcast, engineering, simulation and collaboration environments.
