LEO XST65-160/92 Electric Water Pump

Description

The LEO XST65-160/92 Electric Water Pump is a heavy-duty single-stage centrifugal pump designed for transferring clean water and non-aggressive liquids with similar physical and chemical properties. It is widely used in water supply systems, pressure boosting, HVAC, irrigation, fire protection, and industrial applications. Manufactured according to EN733 standards, the pump features a durable cast iron body, a stainless steel shaft, a high-efficiency impeller, and a 100% copper-wound motor for reliable long-term performance.

Technical Specifications:

• Brand: LEO
• Model: XST65-160/92
• Product Type: Centrifugal Electric Water Pump
• Power: 9.2 kW
• Voltage: 380 V
• Frequency: 50 Hz
• Rated Flow Rate: 72 m³/h
• Maximum Flow Rate: 120 m³/h (2000 L/min)
• Rated Head: 30 m
• Maximum Head: 33 m
• Maximum Suction Depth: 8 m
• Pump Body: Cast Iron
• Shaft Material: Stainless Steel
• Inlet / Outlet Size: 80 / 65 mm
• Protection Rating: IP54
• Insulation Class: F
• Maximum Liquid Temperature: +85°C
• Maximum Working Pressure: 10 bar

Advantages:

• EN733 standardized design
• Flow rate up to 120 m³/h
• Maximum head up to 33 meters
• Heavy-duty cast iron construction
• Stainless steel shaft
• 100% copper-wound motor
• Energy-efficient and low-noise operation
• Ideal for water supply, HVAC, irrigation, pressure boosting, and industrial systems.
