Description
Siemens SQM33.511A9 is a professional actuator designed for precise positioning of air and gas dampers and other burner control elements. It provides a maximum rated output torque of 3 Nm and is controlled by a burner control or electronic management system. The Siemens catalog specifies this model with a 3.6 m cable.
The actuator operates at 24 V, supports an operating angle of up to 90° and uses a stepper motor for precise positioning. The SQM33 series is designed for burner applications including air/gas damper control and adjustment of combustion air and fuel.
The maximum holding torque is 3 Nm with power applied and 2.6 Nm without power. Its robust construction, IP54 protection and operating temperature range of -20 °C to +70 °C make it suitable for industrial burner and heating systems.
Key Specifications
- Brand: Siemens
- Model: SQM33.511A9
- Product type: Actuator / servo actuator
- Application: Burners, air and gas dampers
- Supply voltage: 24 V
- Maximum rated torque: 3 Nm
- Holding torque with power applied: 3 Nm
- Holding torque without power: 2.6 Nm
- Operating angle: 0–90°
- 90° running time: 5–120 seconds, depending on the control system
- Motor type: Stepper motor
- Positioning resolution: up to 0.2°
- Cable length: 3.6 m
- Radial bearing load: up to 100 N
- Axial bearing load: up to 10 N
- Protection rating: IP54
- Operating temperature: -20 °C to +70 °C
- Maximum humidity: 95%
- Power consumption: approx. 10 W
- Weight: approx. 1.4 kg
Advantages
- Up to 3 Nm output torque
- Designed for burner control systems
- Precise air and gas damper positioning
- 0–90° operating range
- Stepper motor for accurate positioning
- 24 V operation
- IP54 protection
- Suitable for -20 °C to +70 °C operating conditions
- 3.6 m cable for convenient installation
- Suitable for industrial boilers, burners and heating systems
